Custom Hollow Mortising Chisel Bit A&I Style Blacken Grinding Suppliers, Factory, For Sale

Hollow Mortising Chisel Bit A&I Style Blacken Grinding

Description:

※Either made from high quality carbon steel or equality better materials.

※The walls of the chisel point are all equal in thickness for superior long lasting performance.

※ All metric chisels and imperial sizes from 1/4" to 1-3/16" , and the shanks are 3/4" or 5/8".


※Shank	※Chisel body & bit	※ Four teeth	※Bit point

Dimension marking:

Product Details

A&I STYLE: BLACKEN G RINDING

Item No.	D	L	L1	3/4 d	5/8 d	3/4 d2	5/8 d2 I
U1102060	6	210	43	19	15.87	4.55	4.55
U1102063	6.35	210	43	19	15.87	4.55	4.55
U1102079	7.94	210	47	19	15.87	5.85	5.85
U1102095	9.5	210	61	19	15.87	6.85	6.85
U1102100	10	210	72	19	15.87	6.85	6.85
U1102110	11	210	72	19	15.87	8.05	8.05
U1102120	12	210	72	19	15.87	9.3	9.3
U1102127	12.7	210	72	19	15.87	9.85	9.85
U1102140	14	210	72	19	15.87	10.1	10.1
U1102150	15	218	92	19	15.87	11.8	10
U1102159	15.9	218	92	19	15.87	12	10
U1102180	18	225	92	19	15.87	12	10
U1102190	19	225	92	19	15.87	12	10
U1102200	20	225	92	19	15.87	12	10
U1102220	22	225	92	19	15.87	12	10
U1102254	25.4	225	92	19	15.87	12	10
U1102300	30	225	92	19	15.87	12	10

unit: mm

Zhejiang Urus Tools Co.,Ltd is famous China Hollow Mortising Chisel Bit A&I Style Blacken Grinding Suppliers and Custom Hollow Mortising Chisel Bit A&I Style Blacken Grinding factory since 1995. Accept OEM and ODM. Mainly exported to Europe, America, Japan and other countries. Our laboratory was officially certified by TÜV Rheinland as cooperative testing lab, and our company was awarded as national high-tech enterprise. Company has passed ISO9001:2015 quality management system, ISO14001:2015 environment management system and OHSAS 18001:2007 OH&S management system. Plant area over 65000 square meter, 100+ employee.
